KPM Minimoto
1 / 5
| MOTOR FRAME SIZE | 60 mm / 70mm / 80mm / 90mm / 100mm |
| MOTOR TYPE | INDUCTION MOTOR / REVERSIBLE MOTOR / TORQUE MOTOR / SPEED CONTROL MOTOR |
| OUTPUT POWER | 6W / 15W / 25W / 40W / 60W / 90W / 120 W / 140W / 180W / 200W/250W (Can Be Customized) |
| OUTPUT SHAFT | 8mm / 10mm / 12mm / 15mm ; Round Shaft, D-Cut Shaft, Key-Way Shaft (Can Be Customized) |
| VOLTAGE TYPE | 110V, 120V, 220V, 230V, 380V, 415V |
| FREQUENCY | 50/60Hz |
| ACCESSORIES | Terminal Box / Fan / Thermal protector / Electric Brake / Controller |
| GEARBOX FRAME SIZE | 60 mm / 70mm / 80mm / 90mm / 100mm |
| GEAR RATIO | 3K-200K |
| TYPE OF PINION | GN Type / GU Type |
| GEARBOX TYPE | Regular Square Case gearbox / Right Angle Gearbox / L Type Gearbox |
We have a wide range of micro motor production lines in the industry, including DC Gear Motor, AC Gear Motor, Planetary Gearbox, Drum Motor, Planetary Gearbox etc. Through technical innovation and customization, we help you create outstanding application systems and provide flexible solutions for various industrial automation.
We will choose the right model and transmission solutions for your usage depend on your specific parameters.
If you need more product parameters, catalogues, CAD or 3D drawings, please contact us.
We can modify standard products or customize them to meet your specific needs.
Induction motors have single-phase type and three-phase type. This kind of motors do not only use electromagnetic coils and capacitors during starting, but also during operation. Although the starting torque is not very large, but it has a simple structure, high reliability, high efficiency and could continuously work. It is widely used in automation industry, logistics, assembly line and etc.
